Morpheus8 | Fractional RF Microneedling Handpiece | STERN Laser

InMode Handpiece $Morpheus8 fractional RF microneedling handpiece by InMode$

InMode · Fractional RF Microneedling Handpiece

Morpheus8

The gold standard in fractional RF microneedling — combining radiofrequency energy with adjustable-depth needling for dramatic subdermal remodelling and skin renewal with minimal downtime. The Morpheus8 24-pin handpiece treats the face, neck, and delicate areas with precision and safety across all skin types.

Up to 4mm DepthAdjustable-depth needling for precise subdermal energy delivery on face and neck

24-Pin TipPrecision tip for facial contouring, periorbital, and delicate treatment zones

Fractional RFBipolar 1MHz RF for collagen stimulation, skin tightening, and acne scar treatment

All Skin TypesSafe on Fitzpatrick I–VI with insulated needles that protect the epidermis

Enquire Now

Clinically proven

SA distributor support

Training included

Areas Treated

Morpheus8 is optimised for facial and neck treatments, as well as delicate body areas requiring precise, controlled RF energy delivery. The 24-pin tip provides fine resolution across contoured facial anatomy.

Face — Full

Full-face remodelling for skin laxity, enlarged pores, texture irregularity, and early jowling. Depth 1–4mm depending on tissue thickness and target indication.

Periorbital

Under-eye crepiness, hooding of the upper eyelid, and crow's feet. Use shallow depths of 0.5–2mm with reduced energy settings. Protective eye shields required.

Neck & Jawline

Skin tightening and collagen stimulation along the jawline and upper neck for improved definition and laxity reduction.

Acne Scars

Multi-pass fractional RF remodelling for atrophic acne scars — rolling, boxcar, and ice pick. Combines needle trauma with dermal RF heating to remodel fibrous scar tissue.

Stretch Marks

Fractional treatment for striae on body areas requiring more precise treatment than Morpheus8 Body provides — inner arms, breasts, and smaller zones.

Décolletage

Skin tightening and texture improvement across the chest and upper sternum region with adjustable depth based on skin thickness.

Treatment Parameters

Morpheus8 face and neck treatment parameters. All settings should be confirmed by your InMode-trained clinician based on individual patient assessment and skin type.

Area	Mode	Energy Levels	Depth	Passes
Full Face (skin laxity)	Cycle	15–25	2–4mm	1–3
Periorbital	Cycle	5–15	0.5–2mm	1–2
Neck & Jawline	Cycle	15–20	2–3.5mm	1–2
Acne Scars	Burst	20–30	3–4mm	2–3
Décolletage	Cycle	10–20	1.5–3mm	1–2

Clinical Notes

Topical anaesthetic should be applied 45–60 minutes prior to treatment. Apply firm, consistent pressure with full tip contact for each pulse. 30% overlap between placements. Dark skin types (Fitzpatrick V–VI): do not exceed energy level 20; use a bleaching regimen pre-treatment and consider fractional settings.

Technical Specifications

Core technical parameters for the Morpheus8 24-pin handpiece. Contact your STERN Laser representative for full clinical documentation.

Handpiece Type	Fractional RF microneedling — face & neck
Tip Configuration	24-pin — standard facial tip
Treatment Depths	0.5mm, 1mm, 1.5mm, 2mm, 2.5mm, 3mm, 3.5mm, 4mm
Maximum Treatment Depth	5mm (4mm thermal profile + 1mm additional heat profile)
Delivery Modes	Cycle, Fixed (stacking), Burst (multi-layer)
RF Frequency	1 MHz bipolar
Skin Types	Fitzpatrick I–VI (dark skin: max energy 20, bleaching regimen recommended)
Treatment Schedule	1–3 sessions every 3–6 weeks; maintenance every ~6 months
Compatible Workstations	EmpowerRF, Morpheus8 workstation, Optimas, Optimas Max

FAQs

Common questions about Morpheus8 face and neck treatments. Contact STERN Laser for clinical guidance specific to your practice.

Morpheus8 uses a 24-pin tip optimised for facial and neck anatomy — smaller treatment area per pass, finer resolution, and shallower depth range (up to 4mm + 1mm thermal). Morpheus8 Body uses a larger 40-pin 3D Smart Frame tip for efficient coverage of broad body zones, reaching up to 7mm + 1mm thermal for deeper subdermal adipose remodelling. Both share the same delivery modes and RF technology.

Morpheus8 treats skin laxity, enlarged pores, fine lines, rhytids, atrophic acne scars, irregular skin texture, early jowling, neck laxity, periorbital crepiness, and stretch marks on delicate body zones. It can also be combined with PRP or skin boosters for enhanced results.

Patients can expect 2–5 days of visible redness, mild swelling, and micro-puncture dots. Makeup can typically be applied within 24–48 hours once the needle marks have closed. Deeper or higher-energy treatments may extend visible redness to 5–7 days. Sun avoidance and SPF are essential post-treatment.

Morpheus8 should not be performed over active acne lesions or infected skin. Treatment of acne scars is appropriate once active acne is adequately controlled. For patients with a history of acne, prophylactic antibiotic cover may be considered.

Platform Compatibility

Compatible Workstations

Morpheus8 is compatible with multiple InMode workstations available through STERN Laser, giving your practice the flexibility to deploy the handpiece across your existing platform.

By InMode

EmpowerRF

The multi-functional women's wellness and aesthetics platform. Morpheus8 is one of seven compatible handpieces, extending the platform to precision facial remodelling.

View workstation

By InMode

Optimas

InMode's flagship multi-technology platform combining laser, RF, and light-based applications — Morpheus8 adds fractional RF microneedling to the full device suite.

View workstation
